FLIR E6 Pro
FLIR E6 Pro
FLIR E6 Pro Infrared Camera with Ignite Cloud
The FLIR E6 Pro is a robust thermal camera designed for efficient use in building surveys, HVAC, automotive, and electrical/mechanical inspections. With a 240×180 thermal resolution and FLIR’s patented MSX® enhancement, it allows quick problem identification. The 3.5-inch touchscreen (640×480) streamlines workflow, enabling photo editing, note addition, and direct file uploads to FLIR Ignite cloud, which is accessible from any device, generating quick reports, facilitating easy image sharing with clients.
-
CRISP RESOLUTION
See impending failures sooner with optics always in focus and large, sharp, 640×480 touchscreen.
-
CONNECTIVITY
Save time by connecting to the cloud for automatically storing, editing and sharing images in FLIR Ignite or Thermal Studio. OTA (Over The Air) updates will always keep your camera equipped with the latest features.
-
MULTI-SPECTRAL DYNAMIC IMAGING (FLIR MSX)
FLIR MSX Image Enhancement provides extraordinary thermal imaging details, with a 5 MP visual camera and LED lamp for improved decision support.
-
INSPECT EFFICIENTLY
Simplify workflow by using the Delta T (NFPA 70B compliant), touchscreen to 1-touch level & span, pan and zoom, as well as adding comments to images – automatically inserted into reports.
-
LIGHTWEIGHT & DURABLE
Rugged, reliable, yet lightweight design with power grip for one-handed, point and shoot image capture.
Is the FLIR E6 Pro not quite enough for what you need? Consider upgrading to the E8 Pro, ← click this link to find out more about it.
–
You can find out more about the FLIR E6 PRO by clicking the link and heading over to Di-LOG Energy.
Di-LOG Energy is a part of the Di-LOG group, for more information click the link to view our group divisions.
Specifications
| Feature by Camera | FLIR E6 Pro |
| IR Sensor | 240 × 180 pixels (43,200 pixels) |
| Thermal Sensitivity/NETD | <0.06°C (0.11°F) / <50 mK at 30°C (86°F) |
| Image adjustment | Automatic adjust/lock image |
| Common Features | |
| Field of View (FOV) | 33° × 25° |
| Minimum Focus Distance | 0.36 m (1.18 ft) |
| USB 3.0 | Peer-to-peer or network |
| Image Frequency | 9 Hz |
| Focus | Focus free |
| Wi-Fi | Peer-to-peer (ad hoc) or infrastructure (network) |
| Detector type | Uncooled microbolometer |
| Spatial resolution (IFOV) | 2.5 mrad |
| Display | 3.5 inches 640 × 480 colour LCD |
| Image modes | Thermal MSX, Thermal, Picture-in-Picture, Digital camera |
| Multi Spectral Dynamic Imaging (MSX) | IR image enhanced with visible camera detail |
| Picture-in-Picture | IR area on visual image |
| Colour palettes | Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Digital camera resolution / FOV | 640 × 480 / 33° × 25° |
| Measurement Features | |
| Object temperature range | -20°C to 550°C (-4°F to 1022°F) in two ranges |
| Accuracy | ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F) |
| Spotmeter / area | Center spot; box with min./max |
| Emissivity table / correction | Emissivity; matt/semi-matt/semi-gloss + custom value, Reflected apparent temperature, Atmospheric compensation |
| Additional Data | |
| Visual Video Streaming | Yes |
| File formats | Standard JPEG,14-bit measurement data included |
| Interfaces | USB Micro: Data transfer to and from PC and Mac device |
| Battery type & operating time | Rechargeable 3.6 V Li ion battery; approx. 4 hours typical use |
| Encapsulation / drop | IP 54 (IEC 60529) / 2 m (6.6 ft) |
| Camera weight, incl. battery | 0.590 kg (1.30 lb) |
